TeraFlex JK HD Tie Rod & Drag Link Kit
Description
The TeraFlex HD Tie Rod & Drag Link Kit is designed for extreme conditions that typically cause factory steering components to bend and fail.
HD Tie Rod Features:
• HD 1.6” O.D. 4140 heat treated chromoly
• Over 200% stronger than factory tie rod
• Forged tie rod end housing designed specifically for JKs
• Allows proper clearance for use with factory 17” wheels
• Tie rod end joint incorporates same features found in TeraFlex ball joints, including 4140 chromoly ball/stud and 1045 carbon steel housing
• Also features adjustable preload tension to ensure proper long term durability
• Includes the clamp #1123160, or the TeraFlex Steering Stabilizer Relocation Kit
The joint is pressed into the rod end housing and secured with a snap ring. When oriented in the Tie Rod configuration, the joint offers a total of 14 degrees movement to minimize tie rod roll, but will still allow maximum turning.
HD Drag Link Features:
• 1.25” O.D. fully forged drag link eliminates excess movement during hard steering maneuvers
• Utilizes oversized DOM factory style adjusting collar and pinch clamp for simple adjustments
• Tie rod end joint incorporates same features found in TeraFlex ball joints, including 4140 chrome moly ball/stud and 1045 carbon steel housing
• Adjustable preload tension to ensures proper long term durability
• Joint is pressed into rod end housing and secured with snap ring
• Fits OEM 17" wheel
