FOX 2.5" DSC - Dual Speed Compression
Front Pair
Performance Elite Series 2.5 Reservoir smooth body shocks give you enhanced ride quality and the control you need when heading off the pavement. They take their design from our Off-Road race shocks, so they've been thoroughly perfected in brutal conditions that you will probably never see. Our athletes push the boundaries in competition to develop race-proven performance you can bolt onto your Truck or SUV.
The external reservoir allows for increased oil and nitrogen capacity while delivering a striking race look. Applications are available to fit most stock and lifted Trucks and SUVs. Our complete line of bolt-on, Performance Elite shocks provide improved damping in any terrain. Experience for yourself the incredible performance and precise control that Performance Elite Series 2.5 Reservoir shocks deliver.
Body: 2.5" impact extruded and CNC machined 6061-T6 hard anodized aluminum body resists rust over time
Body Plating: Hard-anodized for a durable finish
Reservoir: External reservoir design separates shock oil from the high-pressure nitrogen
Components: Black-anodized, CNC-machined 6061-T6 billet aluminum
Shaft: 7/8" hard chrome plated heat-treated alloy steel
Piston: Race-developed high-flow piston design
Valving: Application specific valving to maximize performance
Seals: Redundant sealing pack system main seal, wiper seal, scraper seal
Bearing: PTFE-lined, heat-treated, alloy steel spherical
Adjuster Type: DSC - Dual Speed Compression
Extended: 28.510
Compressed: 17.340
Travel: 11.170
Top Mount: Eyelet
Bottom Mount: Eyelet
Fitment notes: Includes Universal Bracket
Extended (in): 28.5100
Compressed (in): 17.3400
Travel (in): 11.17
